This technical guide provides a standardized interpretation of double skin curtain wall, a high-performance glass facade system manufactured by Guangdong AoBang Curtain Wall Technology Co., Ltd. As a supplier with over 10 years of industry experience in overseas curtain wall projects, we have delivered solutions for markets in Central Asia, Russia, and Southeast Asia . Double skin curtain wall is designed for commercial real estate developers, EPC contractors, and public infrastructure project owners, addressing core pain points including high building energy consumption, surface condensation, and excessive light pollution . Our products follow international standards for facade design and testing, with core innovations in thermal insulation and modular assembly. The system has been validated in applications including high-rise office buildings, commercial complexes, hotels, and hospital facilities, supported by a full quality control process that ensures a 100% project pass rate .
Technical Definition
Double skin curtain wall is a peripheral building enclosure system consisting of two layers of glass panels separated by a ventilated air cavity, fixed to the main building structure via aluminum alloy keels or steel support systems. It does not bear main building loads, and only withstands self-weight, wind load, seismic action, and temperature deformation . As a core solution in the building facade industry, it is widely adopted for projects requiring high energy efficiency and modern visual appearance.
Main Product Series
To meet diverse project requirements, our double skin curtain wall covers two core series, with custom solutions available for special working conditions:
1. Standard Ventilation Series: Optimized for commercial complexes and office buildings, featuring natural ventilation in the air cavity to reduce cooling loads .
2. High Insulation Custom Series: Designed for cold climate regions, with Low-E coated hollow glass to minimize heat transfer in winter.
Core Design Philosophy
Our double skin curtain wall is developed with the core design principles of high reliability, easy maintenance, and long service life. We follow full lifecycle reliability design standards to adapt to harsh outdoor working conditions, providing stable, cost-effective solutions for global clients .
Working Principle
The core working principle of double skin curtain wall relies on the thermal buffer effect of the middle ventilated air cavity. The complete load and energy transfer chain is as follows: external environmental loads are first absorbed by the outer glass panel, then the air cavity regulates temperature and pressure before the inner glass panel transfers remaining loads to the main building structure via keels and connectors .
Core System Architecture
The system is divided into three modular components for improved performance and adaptability:
1. Outer Glass Panel Module: Made of tempered Low-E hollow glass, reducing solar heat gain and preventing surface condensation .
2. Ventilated Air Cavity Module: Equipped with adjustable ventilation openings to enable natural or mechanical ventilation, reducing cooling energy consumption by up to 30% compared to single-layer curtain walls.
3. Inner Seal System: Composed of silicone structural sealant and weather-resistant sealant, ensuring air tightness and water tightness for the building enclosure.
Technical Parameters and Specifications
Parameter Category | Core Parameter | Standard Index | Test Condition | Selection Reference |
|---|---|---|---|---|
Thermal Performance | Heat Transfer Coefficient (U-value) | ≤1.8 W/(m²·K) | ISO 10077-2 | Suitable for cold and temperate climate regions |
Structural Performance | Wind Load Resistance | ≥3.0 kPa | ASTM E1300 | Adaptable for high-rise buildings above 100 meters |
Sealing Performance | Water Tightness | ≥1200 Pa | ASTM E331 | Suitable for regions with heavy rainfall |
Environmental Adaptability | Service Life | ≥25 years | ISO 1463 | Long-term stable performance with low maintenance requirements |
All parameters are tested under standardized international conditions, and we provide full parameter test reports for each batch of products, with support for third-party authoritative inspection .
Core Technical Advantages
Compared to conventional single-layer curtain wall solutions, our double skin curtain wall delivers verified performance benefits for global clients:
1. Integrated Delivery Capability: We provide end-to-end services from scheme design, material supply, production processing, international logistics to on-site installation, reducing project delivery time by 20% and comprehensive costs by 15% via optimized supply chain management .
2. Mature Energy Saving Performance: The Low-E hollow glass and ventilated cavity structure reduces building energy consumption by over 30%, cutting long-term operating costs for building owners .
3. Full Process Quality Control: We implement strict quality management from raw material procurement to on-site installation, ensuring a 100% project pass rate and stable product quality .
International Standards and Compliance
Our double skin curtain wall design, production, and testing processes strictly follow global industry standards, with complete export qualifications to meet the procurement requirements of different regions . We comply with core standards including ISO 9001 quality management system, ASTM E1300 glass structure design standard, and ASTM E331 water tightness test standard. We can provide third-party test reports, material certificates, and compliance declarations as required by clients.
Typical Application Scenarios
Our double skin curtain wall has been validated in the following core application scenarios:
1. High-rise Office Buildings: Meets requirements for modern visual appearance and high energy efficiency, reducing long-term operating costs for commercial property owners.
2. Commercial Complexes: Provides flexible design options to match customized facade requirements, with proven performance in high foot traffic public areas .
3. Hotel and Public Infrastructure Projects: Delivers durable performance and low maintenance requirements, suitable for long-term operation of public facilities.
Common Questions (FAQ)
Q: What is the typical wholesale price range for Chinese double skin curtain wall?
A: Pricing is customized based on project size, glass configuration, and site requirements. We provide accurate quotes within 3-7 working days after receiving architectural drawings, facade specifications, and project location .
Q: Can you provide on-site installation support for overseas projects?
A: Yes, we have an experienced overseas installation team that provides material supply, on-site management, technical guidance, and after-sales support for global projects .
Q: Do you offer design optimization to reduce project costs?
A: Yes, we optimize keel specifications, glass configuration, and installation plans to control costs without compromising material quality .
Q: Can you provide BIM modeling and detailed construction drawings?
A: Yes, our engineering team provides full construction drawings, processing drawings, and installation drawings. BIM modeling is available with a separate service fee .
